gefran VDI100 Start-Up And Installation Manual

Group 01: V/f Control Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
01-00 V/f Curve Selection 0~FF F - O O X X X X O *3
01-01 Reserved
01-02
Maximum Output Frequen-
cy of Motor 1
4.8~599.0 50.0/60.0 Hz O O O O O O O *8
01-03
Maximum Output Voltage of
Motor 1
0.2~510.0 400.0 V O O X X X X O *8
01-04
Middle Output Frequency 2
of Motor 1
0.0~599.0 0.0 Hz O O X X X X O
01-05
Middle Output Voltage 2 of
Motor 1
0.0~510.0 0.0 V O O X X X X O *8
01-06
Middle Output Frequency 1
of Motor 1
0.0~599.0 3.0 Hz O O X X X X O
01-07
Middle Output Voltage 1 of
Motor 1
0.0~510.0 * V O O X X X X O *8
01-08
Minimum Output Frequency
of Motor 1
0.0~599.0
VF:1.5
Hz O O O O O O O
VF+PG:
1.5
SLV: 0.6
SV:0.1
PM SV:0.1
PM SLV:9.0
SLV2: 1.0
01-09
Minimum Output Voltage of
Motor 1 (for 2.2~22kW)
0.0~510.0 7.5 V O O X X X X O
01-10 Torque Compensation Gain 0.0~2.0 0.5 - O O X X X X O *1
01-11
Selection of Torque Com-
pensation Mode
0: Torque Compensation Mode 0
0 - O O X X X X X
1: Torque Compensation Mode 1
01-12 Base Frequency of Motor 1 4.8~599.0 50.0/60.0 Hz O O O O O O O
01-13
Base Output Voltage of
Motor 1
0.0~510.0 400.0 V O O X X X X O
01-14 Input Voltage Setting 310.0~510.0 400.0 V O O O O O O O
01-15 Torque Compensation Time 0~10000 200 ms O O X X X X O
01-16
Maximum Output Frequen-
cy of Motor 2
4.8~599.0 50.0/60.0 Hz O X X X X X X
01-17
Maximum Output Voltage of
Motor 2
0.2~510.0 400.0 V O X X X X X X
01-18
Middle Output Frequency 2
of Motor 2
0.0~599.0 0.0 Hz O X X X X X X
01-19
Middle Output Voltage 2 of
Motor 2
0.0~510.0 0.0 V O X X X X X X
01-20
Middle Output Frequency 1
of Motor 2
0.0~599.0 3.0 Hz O X X X X X X
01-21
Middle Output Voltage 1 of
Motor 2 (for 2.2~22kW)
0.0~510.0 S V O X X X X X X
01-22
Minimum Output Frequency
of Motor 2
0.0~599.0 1.5 Hz O X X X X X X
01-23
Minimum Output Voltage of
Motor 2 (for for 2.2~22kW)
0.0~510.0 S V O X X X X X X
01-24 Base Frequency of Motor 2 4.8~599.0 50.0/60.0 Hz O X X X X X X
01-25
Base Output Voltage of
Motor 2
0.0~510.0 400.0 V O X X X X X X
01-26
V/f Curve Selection of
Motor 2
0~FF F - O X X X X X X *3
*: Refer to the attachment 1.
30 VDI100 • Start-up and Installation Manual
