gefran VDI100 Start-Up And Installation Manual

Group 22: PM Motor Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
3: Magnetic Pole Alignment
22-22
Fault History of PM Motor
Tuning
0. No Error 0 - X X X X O O X *4
1. Static Magnetic Alignment Fault
2. Without PG Option Card
3. Rotation Pole Alignment is Forced to
Stop
4. Error of Encoder Feedback Direction
5. Loop Adjustment is Time out
6. Encoder Error
7. Other Errors of Motor Tuning
8. Current Abnormity Occurs when
Aligning Rotation Magnetic Pole
9. Current Abnormity Occurs while Loop
Adjustment
10. Reserved
11. Stator Resistance Measurement
Timeout
22-23 Reserved
22-25
Detection Mode Selection
of Initial Magnetic Pole
0: Upon the angle before stopping
1 - X X X X O O X Note 1
1: Mode 1
2: Mode 2
3: Mode 3
22-26 Estimator Mode 0~1 (in PMSLV mode) 0 - X X X X X O X Note 1
22-27
Voltage Command of Mode
2
5~100
(22-25=2 or 22-26=1 is enabled)
50 % X X X X O O X Note 1
22-28 Divider Ratio of Mode 2
0~4
(22-25=2 or 22-26=1 is enabled)
2 - X X X X O O X Note 1
22-29
Flux-weakening Voltage
Command Restriction
80~100
(related to parameter 22-18)
95 % X X X X O O X Note 1
Note 1: New added parameter in software V1.20
VDI100 • Start-up and Installation Manual 63
