Chap. 3 — page 9
L.GEISMAR Company – Prohibited Reproduction©
HYDRAULIC RAIL THREADER H90461 / NO 10055
TYPE MPR – M
Chapter 3 – Technical characteristics
3 – 1 General characteristics
Manufacturer Société des Anciens Établissements L.GEISMAR
Address 5, rue d’Altkirch 68000 COLMAR
Machine
HYDRAULIC RAIL THREADER
Type
MPR – M
Code
H90461 / NO 10055
Series n°
Creation date
03/11
General characteristics
Overall length with extensions: 3722 mm
Overall length without extensions: 3058 mm
Overall width: 1620 mm
Height of retracted lifting cylinder rods: 1352 mm
Height of extended lifting cylinder rods: 1614 mm
Lifting cylinder travel 500 mm
Weight: 1125 Kg
Number of wheels: 4 (non-isolated)
Wheel diameter: 100 mm
Number of drive wheels: 2
Clamp lighting: 2 x 15 W
Performance
Motorised trolley travel speed 0 to 3.5 km/h
Shifting cylinder thrust 1000 DaN (1 t)
Shifting cylinder tensile strength 500 DaN (0.5 t)
Lifting capacity WLL 4500 Kg
