H90461 / NO 10055 HYDRAULIC RAIL THREADER
TYPE MPR – M
Chap. 4 — page 23
L.GEISMAR Company – Prohibited Reproduction©
4 – 7 – 3 Lining Track
Once the rails have been fastened onto the
sleepers, particularly in case of track renewal, the Rail
Threader can be used as a track liner to straighten the
track. To use the machine as a track liner, a removable
frame is fixed under the bearing base with driftpins.
This removable frame rests on the ballast between two
sleepers. The two drifts (A) (fig.19) are removed from
the double beam to keep the two transfer carriages
apart.
Fig : 19
