Chap. 5 — page 25
L.GEISMAR Company – Prohibited Reproduction©
HYDRAULIC RAIL THREADER H90461 / NO 10055
TYPE MPR – M
Chapter 5 – Operating instructions
5 – 1 Handling instructions
Before any use, we recommend that you refer to chapters:
1.3 - General safety regulations.
1.4 - Particular safety regulations
5 – 2 Preamble
The Rail Threader is manipulated by a single operator; travel must always be in a
forward direction relative to it.
5 – 2 – 1 Reminder of terms used in this chapter
For all manipulation of the Rail Threader, use the following terminology (fig. 20) :
Fig : 20
Before starting a job, make sure that the direction of travel of the Rail
Threader meets this requirement during renewal or replacement operations,
so as to guarantee the operator's safety.
OPERATOR
DIRECTION OF TRAVEL (FORWARDS)
MOTORISED
CARRIAGE
LEFT
RIGHT
HYDRAULIC
CONTROLS
