H90461 / NO 10055 HYDRAULIC RAIL THREADER
TYPE MPR – M
Chap. 5 — page 28
L.GEISMAR Company – Prohibited Reproduction©
Release the clamps using the levers (B), pull the locking
sleeve towards yourself and lift the lever (fig. 26)
Fig : 26
The carriage is moved by the levers (D) in the forward
direction of the unit on the rails, the spacing of which
increases (fig. 27)
Fig : 27
After travelling for 5 to 8 m, the same operations are repeated
B
D
