GEISMAR MPR-M - Page 58

HYDRAULIC RAIL THREADER TYPE MPR – M
IMPORTANT : To allow prompt and correct delivery of spare parts, always state : Fabrication year and n° of the
machine - Serial number - Order n° and description of spare parts
Item Qty Description Code N° Drawing
ÉD : 01/11
HYDRAULIC RAIL THREADER H90461 NO 10055
1 1 FITTED FRAME................................................................................ H90476 ............NO 10055-1
2 1 ENGINE/PUMP UNIT........................................................................ H78414 ............NO 00015-2
3 2 MOTORISED CARRIAGE................................................................. H82606 ............NO 07183-3
4 1 HYDRAULIC OIL TANK .................................................................... H60897 ............NO 00015-4
5 1 HYDRAULIC DIAGRAM.................................................................... H90467 ............NO 10055-8
6 1 ELECTRIC EQUIPMENT .................................................................. H60254 ............NO 00155
7 1 BATTERY SLIDING SUPPORT........................................................ H78375 ............NO 04110-7
9 1 ACCESS DOOR ............................................................................... H09644
10 2 SUPPORT DE FLEXIBLES............................................................... H10127 ............NO 88004-16
11 2 EXTENSION ..................................................................................... H79633
15 1 GAS-OIL ALIMENTATION ................................................................ H60892 ............NO 00015-23
17 4 WASHER .......................................................................................... C01811
18 4 SCREW............................................................................................. C00340
19 8 WASHER .......................................................................................... C01036
20 2 SCREW............................................................................................. C02203
21 16 SCREW............................................................................................. C00355
22 40 WASHER .......................................................................................... C01037
24 14 NUT................................................................................................... C00143
26 PROJECTOR.................................................................................... E04216
27 WASHER .......................................................................................... C02156
28 NUT................................................................................................... C00142
30 1 DESCRIPTIVE PLATE ASSY ........................................................... H88463 ............NO 10055-30
MANIPULATORS FUNCTION
:
A LIFTING
B RAILS GRIPS
C SLEWING
D DRIVING
E ATR-6
..........................................................................................................
F DOUBLE BEAM DRIFTS
