HYDRAULIC RAIL THREADER TYPE MPR – M
IMPORTANT : To allow prompt and correct delivery of spare parts, always state : Fabrication year and n° of the
machine - Serial number - Order n° and description of spare parts
Item Qty Description Code N° Drawing
ÉD : 06/00
FITTED FRAME H90476 NO 10055-1
1 1 BARE FRAME................................................................................... H79624
2 1 PROTECTION FRAME - ENGINE SIDE........................................... H78368
3 1 PROTECTION FRAME – DISTRIBUTION SIDE .............................. H72552
4 2 HOISTING RING............................................................................... H78406
5 12 SCREW............................................................................................. C00357
6 12 WASHER .......................................................................................... C01813
7 12 NUT................................................................................................... C00143
8 8 SCREW............................................................................................. C00401
9 8 LOCKING NUT ................................................................................. C00146
10 8 WASHER .......................................................................................... C01040
12 2 LIFTING CYLINDER ......................................................................... D18062 ...........NO 06180-1-12
13 2 SLEWING CYLINDER ...................................................................... D18064 ...........NO 06180-1-13
14 1 LOWER FRAME ............................................................................... H02035 ............NO 80102-7
15 2 DOUBLE BEAM DRIFT..................................................................... H80667
16 2 COVER PLATE ................................................................................. H78408
17 2 FIXING LUG...................................................................................... H78409
18 4 SCREW............................................................................................. C00370
19 4 WASHER .......................................................................................... C01817
22 8 SCREW............................................................................................. C00341
23 8 WASHER .......................................................................................... C01811
24 4 SCREW............................................................................................. C00400
25 2 COLLAR ........................................................................................... D00608
26 1 COLLAR ........................................................................................... D07091
27 2 SCREW............................................................................................. C00510
