MU-A-RectiRail DL2-rev01a-Gb 38 / 44
7.5 Reading
In this measurement mode, you can read the DA5 files specifically created in the
“grouped measurement, 1 file/group” mode.
- Click on reading
Ref ⑥
As explained in the above section, these files are identified by the suffix “_x”,
automatically added to the DA5 name.
Ref ⑦
The 2 or 3 measurements in the DA5 are displayed on the screen:
7.6 Zoom
Various zoom factors can be used to visualise measurements. Refer to “§6.5 Zoom” for
a complete description of this function.
