7.7 Scan
The scan mode (see §6.6 Scan mode) is accessible via the button ,
but is limited to the display of one curve. Following validation of this mode, the screen
below lets you choose the curve you want to visualise:
Select the curve and validate by
The scan mode is now activated for this curve
(refer to
“§6.6 Scan Mode” for use of this mode):
