MU-A-RectiRail DL2-rev01a-Gb 5 / 44
2 TECHNICAL DATASHEET
Characteristic Value Unit
Dimensions L x H x W 1160 x 160 x 100 mm
Weight (including battery) 5 kg
Measurement range 4 mm
Accuracy ± 50 µm
Resolution 12.5 µm
Storage capacity Limited only by PDA capacity.
Rule autonomy > 800 Readings
PDA autonomy 3-4 Hours
Operating temperature 0~40 °C
EMC conformity Standard EN-50121-4 (2000) * -
* Certificate 2005 SMEE 3370-ATT and reports 3368-EMI, 3369-IMM
Emission: Repository EN-50121-4 (2000), Level EN 55011 Class A
Immunity: Repository EN-50121-4 (2000), Levels ENV 50204 and EN 61000-4-3, 6, 4, 2,
5, 8, and 9
