31 GSM19 Series Magnetometers - Version 7
GEM Systems, Inc. Advanced Magnetometers
For more technical information, visit www.gemsys.ca
If you select X/Y system, the next screen is:
SCREEN 10 x= 0 y= 0
position
x= 0 y= 0
increment
x= 0 y= 0
EOL increment
E-next C-clear D-backsp. F-ok
• Position Current coordinates. These are the X/Y coordinates of the first reading.
• Increment Increase in each direction that is added to present position after each reading.
• EOL End Of Line increment (i.e. added to the present X and Y if you press EOL -see
section 5.4.4)
A list of available commands is shown on the bottom line:
E moves cursor to next number.
C erases the number at cursor position.
D cursor jumps to the end of the number - if you just want to modify last digit.
F leaves this screen.
If you press C-clear or D-backsp, the bottom line changes to display new commands:
SCREEN 11 x= 0 y= 0
position
x= 0 y= 0
increment
x= 10 y= 0
EOL increment
0-9 A-dp B- + D-backsp. E-enter
