33 GSM19 Series Magnetometers - Version 7
GEM Systems, Inc. Advanced Magnetometers
For more technical information, visit www.gemsys.ca
SCREEN 13 STATION 012345.50 E
change A-number B-coordinates
STATION INCREMENT +00012.25
change C-sign D-number
F-OK
A changes station number.
B changes station cardinals. (N,NE,E,SE,S,SW,W,NW)
C changes station increment sign.
D changes station increment.
When you press A - number, D - number or 0 - number the following screen is displayed:
SCREEN 14
E - enter C - clear
Here you can enter the required number, using 0-9 digits and A as a decimal point. Then use C-
clear to make corrections or E-enter to store.
When you press B-coordinates, the following screen is displayed:
SCREEN 15
enter NESW
Use the blue letters on the keyboard to select the desired cardinal point.
