80 GSM19 Series Magnetometers - Version 7
GEM Systems, Inc. Advanced Magnetometers
For more technical information, visit www.gemsys.ca
SCREEN 81
uncorrected field
F - ok C - change
C-change toggles between the options. When you are finished making your selection, press F. The
following screen is displayed.
SCREEN 82
000100N 000575E
..............................
uncorrected field
00100N 0000125E A- B+ C
The upper right corner shows the coordinates of the right most readings. The bottom left corner
shows the coordinates of the left most readings.
A- scrolls the graph backward
B+ scrolls the graph forward
C
displays the following graph setting screen
To change the graph’s settings, press
C. The following screen is displayed:
SCREEN 83
D ↑ vertical scale 20 nT
..............................
C
↓ A- B+ F
To Next Page
