Here you have the following options:
A- reduces the vertical scale
B+ increases the vertical scale
C moves the graph down (keep pressed for continuous action)
D moves the graph up (keep pressed for continuous action)
F returns you to graph review
When reviewing base files:
The upper left corner shows the time (hhmmss) of the left most reading
The upper right corner shows the time of the rightmost reading
A- scrolls the graph backward
B+ scrolls the graph forward
Although base readings are always uncorrected, the label 'uncorrected field' may be shown.
SCREEN 84
123456 125634
.....................................
uncorrected field
A- B+ C
Press C to change the graph's settings
SCREEN 85
D ↑ vertical scale 20 nT
........................
C
↓ A- B+ F
Here you have the following options:
