GEM-P9600 Programming Instructions
L
NAPCO Security Systems
WI777D 08/00
!
Page 12
Key Fob Transmitters
(Press the (
A
) button to set cursor.)
Keyfobs can be programmed as “Arm/Disarm” devices.(refer to WI752).
For each Key Fob Transmitter, enter:
!
the Key Fob Transmitter number (01–16).
!
area number to which transmitter is assigned (1-8); enter 0 to disable
keyfob.
!
the 6-digit RF ID # printed on the transmitter (enter all numbers and/or letters, including
leading “0”s, if any).
! 1-digit checksum number printed on the transmitter (enter all numbers and/or letters,
including leading “0”s, if any).
! Aux-1 Option (see key fob aux 1 & aux 2 options).
! Aux-2 Option (see key fob aux 1 & aux 2 options).
Note:
If the Key Fob is converted for Two Button “Emergency Use” (by cutting an internal
jumper), both top or bottom buttons must be depressed to activate an alarm. In this case,
Aux-1 and Aux-2 cannot be programmed. Press
J
to save. Press NEXT (E) button to
proceed.
Key Fob Zone Assignment (refer to display as shown on the previous page: press the (
F
) button to go backwards.)
Each of the 4 key fob buttons can be assigned to a zone. For example, On button = point 1; Off button = point 2; A1 =
point 3; A2 = point 4. Up to 96 key fobs (using 1 button) or 48 key fobs (using 2 buttons) or 28 key fobs (using all 4
buttons) or any combination up to a maximum of 96 controlled zones can be assigned, providing multiple wireless panic
buttons on a system, each reporting to the Central Station or a pager and/or annunciating on a keypad the key fob zone
number with description/location. To assign a key fob to a zone: program the keyfob as you would a transmitter, entering
the keyfob's ID code, check sum and point number at the appropriate zone. The “Quick Method” is not allowed. The zone
may be hardwired to a sensor as well as assigned to a key fob (either one will activate the zone alarm output). NOTE: If
assigning a key fob to a zone, the “ON/OFF” buttons on the key fob will no longer arm/disarm the system. The key fob is
converted to a “panic only” device.
Enter Zone and Interior Descriptions
Press the
1
and
2
buttons to place the cursor; press the
3
and 6 buttons to select the character. For each zone, enter a
description of up to two lines. Press
J
to save each description. To proceed
to the next description, place the cursor under the Zone Number (e.g. “01”) and change the Zone Number using the
3 and 6 buttons. Program a new description as above.
NOTE:
Zone Descriptions can only be entered through
the GEM-/RP1CAe2 Keypad or by using the Napco Quickloader Software. Press NEXT (
E) button to proceed.
Enter Date
(Press the (
A) button to set cursor.)
Enter the current date in the format MM/DD/YY, where MM = the month
(01–12); DD=the day (01–31); and YY=the year. Press
J
to save. Press
NEXT (
E) button to proceed.
KF A XMIT#+ CS OP
01-0 000000:0 00
DATA
ENTRY
AUX 1/AUX 2 OPTIONS
0None
1 Relay Group 1 Toggle
2 Relay Group 2 Toggle
3 Relay Group 3 Toggle
4 Relay Group 4 Toggle
5 Relay Group 5 Toggle
6 Relay Group 6 Toggle
7 Relay Group 7 Toggle
8 Relay Group 8 Toggle
9Panic
A Auxiliary
B Instant
C Aux. Output Toggle
D Access on Aux. Output
NOTE: Key fobs 1-16 report openings and
closings as Users 81-96.
GEM-RP1CAe2 Keypad: Keyfob Transmitters, Zone Descriptions & Date
(Direct Entry)
01-______________
________________
(Direct Entry)
ENTER DATE
(01/01/99)
