Gemini GEM-P9600 Programming Instructions

L
NAPCO Security Systems
X
GEM-P9600 Programming Instructions
WI777D 08/00
!
Page 35
SYSTEM DELAYS & TIMEOUTS (ADDRESS 0000-0002, 2402, 2406, 2414 & 3902)
ADDRESS 0000
LEFT RIGHT
EXIT
DELAY
(sec.)
[Default = 3C]
ADDRESS 0001
LEFT RIGHT
ENTRY
DELAY 1
(sec.)
[Default = 1E]
ADDRESS 0002
LEFT RIGHT
ENTRY
DELAY 2
(sec.)
[Default = 1 E]
PROGRAMMING TIMEOUTS: Either use the tables provide or calculate your own timeout using the steps indicated.
WARNING: Timers have uncertainty of +/-1sec, so a "time" of 1 second may actually timeout IMMEDIATELY.
ADDRESS 2406
LEFT RIGHT
ABORT
DELAY
(sec.)
[Default = blank (•) blank (•)]
DATA ENTRIES
LEFT RIGHT
blank (•) blank (•)
blank (•) F
1E
2D
3C
50
78
FF
DELAY/
TIMEOUT
0 sec.
15 sec.
30 sec.
45 sec.
60 sec.
90 sec.
120 sec.
255 sec.
!
1. Select delay/timeout (0-255 sec.) from the table shown.
!
2. Enter in corresponding address locations above (left and right digits).
!
3. For a desired delay/timeout not listed do the following:
A. Choose a desired delay/timeout, ex: 20 sec.
B. Divide it by 16
EXIT/ENTRY DELAYS:
Apply only to zones programmed with the following
options “Entry/Exit 1, Entry/Exit 2, Exit/Entry Follower”. For UL Installations, the maximum exit
delay is 60 seconds and the maximum entry delay is 45 seconds.
1 Quotient Left Digit
16 20
16
4 Remainder Right Digit
SYSTEM DELAYS & TIMEOUTS (ADDRESS 2407, 2408 & 4088)
ADDRESS 2407
LEFT RIGHT
CHIME
TIMEOUT
(¼sec.)
[Default = blank (•) 2]
DATA ENTRIES
LEFT RIGHT
blank (•) blank (•)
blank (•) 2
blank (•) 3
blank (•) 4
blank (•) 5
blank (•) 6
blank (•) 7
blank (•) 8
FF
TIMEOUT
0 ¼sec. = 0 sec.
2 ¼sec. = ½ sec.
3 ¼sec. = ¾ sec.
4 ¼sec. = 1 sec.
5 ¼sec. = 1.25 sec.
6 ¼sec. = 1.5 sec.
7 ¼sec. = 1.75 sec.
8 ¼sec. = 2 sec.
255 ¼sec. = 63.25 sec.
CHIME TIMEOUT OPTIONS
[Default = blank (•) blank (•)]
ADDRESS 2408
LEFT RIGHT
AC Fail
Report
Delay
(min.)
DATA ENTRIES
LEFT RIGHT
blank (•) blank (•)
blank (•) 1
blank (•) 2
blank (•) 3
blank (•) 4
blank (•) 5
blank (•) 6
blank (•) 7
FF
DELAY
0 min.
10 min.
20 min.
30 min.
40 min.
50 min.
60 min.
70 min.
2550 min. = 42 Hr., 30 min.
AC FAIL REPORT DELAY OPTIONS
!
1. Select delay/timeout from the table shown.
!
2. Enter in corresponding address locations above (left and right digits).
!
3. For a desired delay/timeout not listed do the following:
A. Choose a desired delay/timeout , ex: 20. Note: For Sensor Watch only divide it by 10, ex: 20/10 = 2
B. Divide it by 16
1 Quotient Left Digit
16 20
16
4 Remainder Right Digit
[Default = blank (•) blank (•)]
ADDRESS 2402
LEFT RIGHT
Aux. Output
Access
Control
Timeout
(sec.)
[Default = blank (•) blank (•)]
ADDRESS 4088
LEFT RIGHT
Sensor
Watch
Delay
(Hr.)
DATA ENTRIES
LEFT RIGHT
blank (•) blank (•)
blank (•) 1
blank (•) 2
blank (•) 3
blank (•) 4
blank (•) 5
blank (•) 6
blank (•) 7
FF
DELAY
0 Hr.
1 Hr.
2 Hr.
3 Hr.
4 Hr.
5 Hr.
6 Hr.
7 Hr.
255 Hr.
SENSOR WATCH OPTIONS
[Default = blank (•) blank (•)]
ADDRESS 2414
LEFT RIGHT
Telephone
Line Test
Delay
(sec.)
System Delays/Timeouts
[Default = blank (•) blank (•)]
ADDRESS 3902
LEFT RIGHT
CS Telco 3
Report
Delay
(sec.)
