B. GEM-RP2ASe2 Keypad
Enter the Master Security Code (printed on microprocessor can) for a new panel or enter your custom
Dealer Program Code if programmed. Press
A
followed by NO (
F) repeatedly until “
TURNON/
PROG
” is displayed.
NOTE:
If you pass “
TURNON/PROG
”, you can scroll back by pressing the B
button. Press YES (E) to enter the Dealer Program Mode. This keypad displays messages in
multiple segments. Press the
A button to scroll through each segment.
Total Number of Zones in Area 1 & Area 2 (Appears for New Panel Only)
Directly enter the total number of zones to be programmed for Area 1 and
Area 2, respectively. Valid entries are from 01 to 96. Directly enter the total
number of zones, including leading zeros. Use number buttons
1
through 9.
NOTE:
Press the 0 button for a zero. The system is
based on groups of 4 zones each (after the first 8 zones), and will
automatically round up to the next group of 4. For example, if you enter 18,
it will automatically convert this to 20 zones. Press
J
to save. Press NEXT
(
E
) button to proceed.
Note:
The GEM-P9600 is limited to a combined maximum of 96 zones and
15 keypads. All 96 zones and 15 keypads may be programmed in the EZ
Program Mode. For more options, see Zone and Keypad Options in Direct
Address Programming.
Fire Zones (Appears for New Panel Only)
Enter the zone number of any Fire Zones (both 2-wire, 4-wire or wireless).
Valid entries are from 01 to 96. Directly enter each zone number, including
leading zeros, and press
J
to save, and then repeat for any additional
zone(s). Press NEXT (
E
) button to proceed.
NOTE: If you are programming a 2 Area system, enter the zone number of
zones required for Areas 1 & 2. All fire zones are common to areas 1 and 2.
The Direct Address Program Mode can then be used to customize them as
needed. See Zone Options.
2-Wire Fire Zones (Appears for New Panel Only)
Enter the zone number of any Fire Zones (from previous question) which
are to be used with 2-wire smoke detectors. The only valid entries are 01-08.
Directly enter each zone number, including leading zeros. Press
J
to save,
and then repeat for any additional zone(s).
NOTE:
Only zones which have
been designated as Fire Zones can be programmed as 2 Wire Fire zones.
Press NEXT (
E) button to proceed.
NOTE:
JP7 must be set to “2-WF”
position for 2-wire fire zones 7 and 8 (refer to Installation Instructions).
R
COMPUTERIZED SECURITY SYSTEM
ARMED
STATUS
SYSTEM ARMED
01/01/97 12:00AM
12
4
3
56
7890
A
B
C
D
E
F
G
NEXT/YES
PRIOR/NO
AREA
GEMINI
ENT A1
A1#Z08
(Direct Entry)
ENT A1
#ZN08
(Direct Entry)
ENT A2
#ZN00
(Direct Entry)
ENT FR
ZN#00
(Direct Entry)
ENT2WF
ZN# 00
GEM-RP2ASe2 Keypad: Zones/Keypads per Area, Fire Zones & 2-Wire Fire Zones
