6 Order data
The order data provide an overview of standard configurations.
Please check the availability before ordering. Other configurations available on request.
Note: A valve specific mounting kit is required for assembly. For designing the mounting kit, the valve type, nominal size, control
function and actuator size must be stated.
Order codes
1 Type Code
Electrical position indicator 1235
Electrical position indicator 1236
2 Fieldbus Code
Without 000
3 Accessory Code
Accessory Z
4 Device version Code
Open/Closed position feedback,
programming input,
high visibility optical position indicator,
IO-Link communication
3E
Open/Closed position feedback,
high visibility optical position indicator
3S
Open/Closed position feedback
programming input,
IO-Link communication
3W
Open/Closed position feedback 3X
Open/Closed position feedback inversed,
programming input,
high visibility optical position indicator,
IO-Link communication
4E
Open/Closed position feedback inversed,
high visibility optical position indicator
4S
4 Device version Code
Open/Closed position feedback inversed
programming input,
IO-Link communication
4W
Open/Closed position feedback inversed 4X
5 Electrical connection Code
M12 plug, 5-pin M125
6 Travel sensor version Code
Potentiometer, 30 mm length 030
Potentiometer, 50 mm length 050
Potentiometer, 75 mm length 075
7 Housing material Code
PVDF base, black, PPR natural cover,
M16 thread PEEK
G10
Base 1.4301, PP cover,
M16 thread, 1.4305
G70
Base 1.4301, PP cover,
M16 thread, 1.4305,
(for GEMÜ 650, actuator size 1, 2, 3
control function 1)
G73
8 Special version Code
UL approval U
Order example
Ordering option Code Description
1 Type 1236 Electrical position indicator
2 Fieldbus 000 Without
3 Accessory Z Accessory
4 Device version 3E Open/Closed position feedback,
programming input,
high visibility optical position indicator,
IO-Link communication
5 Electrical connection M125 M12 plug, 5-pin
6 Travel sensor version 030 Potentiometer, 30 mm length
7 Housing material G70 Base 1.4301, PP cover,
M16 thread, 1.4305
8 Special version U UL approval
6 Order data
www.gemu-group.com 37 / 56 GEMÜ 1235 / 1236
