10 Assembly and installation
10 Assembly and installation
10.1 Preparations for installing the valve (linear actuator)
1. Move the actuator A into zero position (actuator vented).
2. Remove optical position indicator 2 and / or protective cap 1 from the actuator top.
A
1
2
10.2 Preparations for assembly to the valve (quarter turn actuator)
1. Move the actuator A into zero position (actuator vented).
1
2
A
2. Remove the screw 1 from the trigger cam 2.
