Gen2wave RP1100 - Getting Started; RP1100 Technical Specifications

RP1100 User‟s Manual
10
Getting Started
Introduction
This chapter provides information about the RP1100, accessories, charging, and resetting the RP1100.
RP1100 Specifications
Performance Characteristics
Battery(3600mA) Performance
CPU
Marvell PXA320 806Mhz
Standby time
200 hours
OS
Windows Mobile 6.5 Professional
Talk time
7 hours
Memory
256MB SDRAM / 512MB ROM
User profiles
Outdoor WAN+GPS, 3min and
5times/hour voice Communication, 10KB
transmission every 10mins, and GPS on
all time, 8 hours of operation.
Outdoor Voice, 15 min/hour voice
communication, 8 hours of operation and
140 hours standby time.
Communication
Interface
USB HOST 1.1, USB Client 2.0
Ext. Serial RS232C
Physical Characteristics
User Environment
Dimensions
139mm H X 73mm W X 22mm D
Sealing
IP64
Weight
220 ~ 280g (including standard Battery)
Drop Spec.
1.5M drop to concrete.
2 drops per 6 sides
Display
3.5inch. QVGA (VGA, optional)
Operating
Temp.
Main
-10°C ~ +50°C
Input
Touch Panel, 4 direction keys,
6 function keys, 4 side keys, power
Adapter
-10°C ~ +50°C
Battery
Standard : 1860mA/h Li-ion
Extended : 4000mA/h Li-ion
Build-in backup battery : 200mA/h
(polymer)
AC Power
Input : AC 100 ~ 240V, 50 ~
60Hz
Output : DC +5.0V, 3.5A
Expansion Slot
High capacity micro SD Card
Relative Humidity
5% ~ 80%
Audio
Speaker / Receiver / MIC
Used frequency
band
UMTS/HSDPA :
Triple band, 850/1900/2100 MHz
GSM/GPRS/EDGE :
Quad band, 850/900/1800/1900
MHz
Wireless
(WWAN)
3.5G HSDPA (Tri-band)
Quad-band EDGE GPRS GSM
Bluetooth
EDR V2.0 (Intenna, BT Headset support)
Wireless LAN
802.11 b/g
1D Laser Scanner (IS4813)
GPS
Embedded A-GPS
Signal Output
Digital, industry standard
Notification
Vibration and Charging LED, WWAN LED
Resolution:
5 mil (0.127 mm)
Scanner
1D Laser Type
2D Imager
Roll:
42°
Color Camera
Pitch Angle:
68°
Resolution:
3.0 megapixel
Yaw
52°
Illumination:
User controllable flash
Light Source
Visible Laser Diode 650 nm
