Owner’s Manual for Snow Blower 7
General Information and Setup
Know Your Snowblower
(000100a)
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
WARNING
See Figure 2-1. Be familiar with the controls and features
of the unit prior to operation. Read this manual thor-
oughly before assembling and operating this unit. Save
this manual for
future and immediate reference.
Emissions
The United States Environmental Protection Agency (US
EPA) (and California Air Resources Board (CARB), for
engines/equipment certified to California standards)
requires this engine/equipment to comply with exhaust
and evaporative emissions standards. Locate the emis-
sions compliance decal on the engine to determine appli-
cable standards. See the included emissions warranty for
emiss
ions warranty information. Follow the maintenance
specifications in this manual to ensure the engine com-
plies with applicable emissions standards for the duration
o
f the product’s life.
Remove Contents from Carton
1. Remove and verify the carton contains the follow-
ing prior to assembly.
Figure 2-2. Components Included
Item Description QTY
A Discharge chute assembly 1
B Shifter rod assembly 1
C Handlebar assembly 1
D Parts bag 1
Figure 2-3. Large Parts Bag
Item Description QTY
E Plate, adaptor 2
F Handle, shifter 2
G Bolt, M8x55 4
H Washer, 8mm ID X 22mm OD X 4
I Nut, jam, M8 4
J Key, shear bolt, and spark plug tool bag 1
K Cable tie, 7-1/2 in L 5
L Chute hardware and shear bolts 1
Figure 2-4. Small Parts Bag
Item Description QTY
M Key, off switch 2
N Tool, spark plug 1
O Nut, jam, M8 2
P Bolt, shear, auger 2
Q Nut, Hex Lock, M8-1.25 3
R Bolt, Carriage, M8-1.25 X 16MM 3
To Next Page
