Section 5 Disassembly
Diagnostic Repair Manual 69
Figure 5-9. Remove Rotor
Figure 5-10. Engine Ready for Removal
Remove Engine
7. Remove the four nuts from rubber engine mounts.
(Figure 5-11, Item 29)
8. Remove engine.
Reverse procedure for assembly.
004674
004675
