Technical Data
Specifications
Evaporator
Max rotor speed
1745 rpm
Max load per swing
1.5 kg
Max imbalance for opposing swings
10 g
Max operational imbalance
65 g
When only one system in use: 85 g
Dimensions (w x d x h)
Including fume hood
1420 x 817 x 1915 mm
Without fume hood
1346 x 712 x 1685 mm
Width with doors open
1467 mm
Approximate weight
700 kg
Vacuum pump
Type
Oil free scroll
Ultimate system vacuum
< 0.4 mbar
Condenser
Type
Single stage vapour compression
Refrigerant
R404a
Ultimate low temperature
-45°C
Ultimte defrost temperature
+30°C
Pot capacity
4 litres
Chamber material
316L stainless steel
Drain valve
PTFE / 316L stainless steel
Automatic defrost and drain
Yes
Type
Single stage vapour compression
Refrigerant
R404a
Ultimate low temperature
-45°C
Storage / transportation environment
Ambient temperature
0°C to 40°C
Relative humidity
10 o 80% non- condensing
Altitude
Sea level to 12000 m
Operating environment
Ambient temperature
15°C to 30°C
Relative humidity
10 to 60% non-condensing
Altitude
Sea level to 1600 m
Ingress protection rating
IP30
Note: This evaporator is designed for use in a
pollution degree 2 environment (normally only
nonconduictive pollution occurs).
Emissions
Typical noise level is 66 dB (A) at one metre
from the system during normal operation.
For the purpose of air conditioning requirement
calculations, all power consumed by the
system is dissipated as heat.
Extraction requirement for fume hood:
In-flow velocity (min)
0.5 m/s
Extraction pressure
25 to 50 Pa
Electrical
Supply
208 V (±10%) 60 Hz
or 230 V (±10)% 50 Hz
Power PSU 1
2.5 kW
Power PSU 2
2.4 kW
Power PSU 3
2.3 kW
Subtract 600 W from PSU 2
For each evaporator with standard lamps
The system is connected to the mains power supply outlet by three separate mains power cables
(supplied). Power cables supplied are 2 m in length and appropriate to the region to which the unit is
delivered.
Note: To prevent nuisance tripping, the mains power supplies to the evaporator should be fitted with
suitably rated type “D” mains circuit breakers.
