Operator Manual
Introduction 1.7 © Genmega 2012
1.2.5 Main Control Board
Samsung S3C2440AL-40 RISC 32-bit CPU
64 MB RAM
WinCE™ 5.0 Operating System
Modem: 56,000 bps dial-up modem
TCP/IP Ethernet connection - Onboard SSL
Electronic Journal: 40,000 transactions (upload to USB or SD memory Device)
Battery back-up for set-up parameters (NVRAM)
Real time clock
1.2.6 Operating Environment
POWER REQUIREMENTS
110/220 VAC ± 10%, 50/60 Hz, 145 Watts
POWER CONNECTIONS
For warranty purposes, Genmega requires the G2500™ series ATM be connected to a dedicated
power circuit (5amp recommended). This circuit must consist of line, neutral, and ground leads
connected directly to the power circuit breaker panel. This circuit should not be shared with any
other equipment. Use of a surge protector or uninterruptible power supply is recommended.
PHONE LINE REQUIREMENTS
The Genmega G2500 must be connected to a dedicated analog phone line. This line must be a
direct-dial analog line. It is important to disable any voice-mail included on that phone line as it
will cause the ATM not to dial out. This line should not be shared with any other equipment at the
location. Use of shielded (CAT5) phone cable is also recommended for best performance and to
reduce the chance of interference. ‘Digital’ phone lines are NOT supported.
NETWORK (TCP/IP) REQUIREMENTS
For connection to processor via TCP/IP, use an Ethernet Patch-Cable (not included). The ATM
must connect to a device (Router) that can provide DHCP support unless a static IP address is
assigned by the service provider. It is recommended the ATM connect to a broadband router
(Linksys, Netgear, Belkin) or similar device rather than directly to a Cable/DSL modem. For
advanced or corporate networks, provide the IT staff with ATM Host IP address and Host Port
information (available from your ISO).
TEMPERATURE
In storage : 32°F - 123°F (0°C ∼ 49°C)
While operating : 40°F - 95°F (5°C ∼ 35°C)
HUMIDITY
In storage : 10% < RH < 90%, non-condensed
While operating : 15% < RH < 85%, non-condensed
