G-WARE SOFTWARE • TOOLBAR BUTTONS
30
GPIO Builder Button
Add PSR1212 Unit to Current Site Button
The Add a PSR1212 to a Site button opens the Unit Properties—New
Unit window. This is where you configure device ID and modem settings
for the Gentner PSR1212, if you are using one in this system. Adding a
unit to a site is covered in detail on page 23.
Add XAP 800 Unit to Current Site Button
The Add a XAP 800 to a Site button opens the Unit Properties—New Unit
window, where you configure device ID and modem settings. Adding a
unit to a site is covered in detail on page 23.
Gating Control Button
The Gating Control button opens the Gating Control window. This is
where you set parameters for internal and global XAP 800 mixers. The
Gating Controls window can also be accessed by clicking the Gating
Control button on the Preset Configuration Sidebar window. This
section is covered on page 59.
Macro Editor Button
The Macro Editor allows you to add new commands and remove
commands from existing macros. This function is described on page
65.
GPIO Builder Button
The GPIO (general purpose input/output) Builder button opens the
GPIO window, where you can assign commands for the control/status
pins. This gives you real-time flexibility to meet a variety of conferencing
requirements. See page 61 for more information.
Control Panel Builder Button
The Control Panel Builder button opens the Control Panel Builder
window, where you can program the operation of the Control Panel. See
page 62 for more information.
Add PSR1212 Unit to Current Site Button
Gating Control Button
Macro Editor Button
Control Panel Builder Button
Add XAP 800 Unit to Current Site Button
