TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
APPENDIX D • ACCESSORIES
89
Appendix D:
Accessories
Accessory Gentner Part Number
Tabletop Omni Microphone 910-103-160 (with cable)
Tabletop Uni Microphone 910-103-161 (with cable)
Tabletop Omni Microphone 910-103-162 (black button)/910-103-163 (white button)
Tabletop Uni Microphone 910-103-164 (black button)/910-103-165 (white button)
Delta Microphone 910-103-340
Acc. Kit, Side Trim 860-150-002
Wall Mount Speaker 910-103-010
Select Control Panel 910-155-050
Volume Control Panel 910-155-051
Appendix E: Serial
Port Commands
The XAP 800 accepts serial commands through the serial port. The
commands are then channeled along the Expansion Bus network to all
interconnected XAP 800 units. The following commands pertain only to
the XAP 800.
RS-232 serial port protocol is 9,600, 19,200, 38,400 (default), or 57,600
baud; 8 bits, 1 stop bit, no parity.
The structure of serial commands is as follows:
# (indicating the start of a command line), device ID, command, then
any additional options in the order that they appear in the command
descriptions on the following pages.
Commands can be either UPPER CASE or lower case. Return values
are always in upper case. In order for a command to be recognized by
the serial port, the command must be terminated by a carriage return.
For example, a command to disable Automatic Gain Control for Mic 2
on a XAP 800 device "0" would have the command line: #50 AGC 2 M
0. In this command line, 5=XAP 800, 0=unit 0, AGC=command,
2=channel, M= mic group, 0=off state. If a command calls for a "null"
value, leave a blank in the command line (for example, "#50 AGC 2 M"
would return the current AGC state of Mic 2 on device 50).
