G-WARE SOFTWARE • TOOLBAR BUTTONS
31
Define Expansion Bus Ref Button
Command Strings Button
Command Strings Button
The Command Strings button opens the Command String window,
where you enter command strings through the RS-232 port to execute
functions such as increasing volume.
Execute a Preset Button
The Execute a Preset button opens the Execute Preset window, where
you select the saved preset you wish to run. Then click Execute to run
the preset.
Run a Macro Button
The Run a Macro button opens the Run Macro window. Here, you
select which macro you wish to run. Then click Run to initiate the
macro. See the Macro Mode section on page 63 for information about
creating macros.
Define Expansion Bus Ref Button
The Define Expansion Bus Ref button opens the Define PA
Adapt/AEC Expansion Bus Reference window. This window allows you
to set the PA adaptive and acoustic echo cancellation reference for a
particular Expansion Bus. This window also becomes accessible when
configuring specific parameters in the PA Adaptive Reference section
of the Gate configuration window. See pages 43-44 for more
information.
Run a Macro Button
Gating Button
Meters Button
Gating Button
The Gating button opens the Gate View window, which allows you to
view gating activity at each mic input. See page 66 for more
information.
Meters Button
The Meters button opens the Meter Views window, which allows you to
monitor the level of any input, output, or processing signal of the XAP
800. See page 67 for more information.
