G-Ware (setup/diagnostics software)
Dimensions (WxHxD):
17
1
/4
” x 2
3
⁄4
” x 10
1
⁄4
” (43.8 x 7.0cm x 26.0)
Weight:
4.5kg dry
5.9kg shipping
Power Requirements:
Auto-adjusting power module
Fuse: 2 amp, 250VAC, slow-blow type
Input Range:
100-240VAC; 50/60Hz
Power Consumption:
30W, typical
95 BTU/Hr
Phantom Power:
24V, input selectable
Audio Performance
Frequency Response: 20Hz to 20kHz
Noise: (EIN 20Hz to 20kHz) -125dB
THD: <0.003%
Dynamic Range: >100dB
Audio Functions
Filters: All pass; low pass; high pass; low shelving; high shelving; notch;
PEQ; CD horn EQ; and Bessel, Butterworth, and Linkwitz-Riley
crossovers; compressors; matrix mixer w/crosspoint level control;
automatic gain control; and automatic microphone mixer.
Appendices
Appendix A:
Specifications
APPENDIX A • SPECIFICATIONS
81
