APPENDIX E • SERIAL COMMANDS

XAP 800 Serial Commands

Command Function Command Function

AAMB*

†

Selects/reports Adapt Ambient setting

MDMODE Enables/disables modem mode

AMBLVL*

†

Selects/reports Ambient Level

MINIT

Sets/reports modem initialization string of serial prt

AGC*

†

Enables/disables AGC

GRPSEL*

†

Selects/rprts input gating group assignments

BAUD Sets/reports RS-232 port baud rate

MLINE*

†

Selects/reports coarse gain adj. on inputs 1-8

COMPRESS*

Selects/reports comprsr activity for procs.

MMAX*

†

Selects/reports max # mics for each mic gating grp

COMPSEL*

†

MPASS

Sets password setting when using modem mode

MTRX*

Selects/reports matrix routing of an input to output

DECAY*

†

Sets/reports decay rate

DFLTM

Sets/reports default meter

MTRXLVL* Selects/reports matrix level at the cross point

MUTE*

†

Sets/reports mute status

DID Selects/reports device ID

NOM*

†

Selects/reports the NOM setting on output channels

OFFA*

†

Selects/reports Off Atten. mode for inputs 1-8

PAA*

†

Selects/reports PA Adapt mode for specified input

FILTER* Selects/reports inpt/proc channel filter setting

REFSEL*

†

Selects/rprts outpts for mic(s) for PA adapt mode

FILTSEL*

†

Enables/disables filters on inpt/proc channel

FMP*

†

Sets/rprts 1st Mic Prior. for mic gating group

†

Selects/reports phantom power setting

PRESET*

†

Executes preset or reports last executed preset

FPP Sets/reports current pass code setting

PRGSTRING

Sets/reports a programmed string

GAIN*

†

Changes/reports gain for in, out, or proc

GATE Reports gate status of channels 1-8

GHOLD*

†

Selects/reports hold time setting

GMODE*

†

Selects/reports gating mode setting

GOVER*

†

Selects/reports gating override setting

SERMODE Selects/reports the serial mode of the RS-232 port

GRATIO*

†

Selects/reports gate ratio setting

GREPORT Selects/reports gate status report frequency

SIGGEN* Selects/reports signal generator activation

LABEL

Selects/reports label of channel specified

STRING*

†

Sends the specified string out the serial port

LFP

†

Sets/reports status of front panel access

TOUT

Selects/reports the title screen inactivity time-out

CGROUP *

†

Selects/reports compressor group setting

Sets/reports compressor on audio proc. chnl.

DELAY*

†

Sets/reports delay rate

FLOW Selects/reports flow control of serial port

LMO*

†

Selects/reports Last Mic On mode

LVL

Reports in, out, or processor level

LVLREPORT

Selects/reports level status

MACRO*

†

Executes macro or reports last macro executed

MASTER*

†

Reports the mode of the unit

UID

Reports unit ID

VER

Reports unit version

* Command available for macro use.

DELAYSEL*

†

Selects/reports processor channel delay

CHAIRO*

†

Selects/reports chairman override setting

LVLRRATE

Sets the level report rate for the unit

SERECHO

Selects/reports the serial echo of the RS-232 port

MAX*

Changes/rprts max gain sttng for in, out, prcs block

MIN*

Changes/rprts min gain sttng for in, out, prcs block

†

Command available for Control Panel use.

AGCSET

SLVL*

†

Selects/reports AGC settings on inputs

Selects/reports mic auto level setting

AEC Selects/reports acoustic echo canceller setting

SIGTOUT

Sets the signal generator time out for the unit

NLP*

†

NCSEL*

†

NCD*

†

Selects/reports noise canc. on/off for each mic chnl

Selects/rprts noise canc. amount for each mic chnl

Selects/reports non-linear proc. for each mic channl

MINMAX

Changes/reports min and max gain for in, out, proc

DSPVER Reports DSP firmware version
