GeoMax Zenith60 Series User Manual

2 Description of the System
2.1 System Components
Component Description
Zenith60 A GNSS smart antenna with integrated communication devices.
Field controller A multi-purpose device enabling the control of GeoMax instru-
ments.
Zenith60 WebManager A web-based user interface used to manage the GNSS smart
antenna.
2.2 Container Contents
22997_002
a
b
e
l
c
d e
f
j
k
h
i
g
a Zenith60 instrument
b Batteries
c Tablet
d Power adapter
e Measuring tape*
f Field controller
g Cables
h Pole clamp
i Charger
j UHF antenna arm* and
UHF radio antenna*
k Carrier*
l Tribrach*
*optional
22998_002
a
b
a Pole 25 cm
b Quick Guide
2.3 System Concept
2.3.1 Software Concept
The software can be uploaded using Zenith60 WebManager.
☞
Refer to 4.1.6 Zenith60 WebManager.
Main components
Container for Zenith60
instrument and accessor-
ies part 1 of 2
Container for Zenith60
instrument and accessor-
ies part 2 of 2
Software upload
