GeoMax Zenith60 Series User Manual

4.3 Inserting a microSD/SIM Card
•
Keep the card dry.
•
Use it only within the specified temperature range.
•
Do not bend the card.
•
Protect the card from direct impacts.
Failure to follow these instructions could result in data loss and/or permanent damage to the
card.
Inserting a microSD card
1b
1b
1b
1a
1a
1a
3
3
2
2
4
4
25154_001
☞
Removing the microSD card while the instrument is turned on can cause loss of
data. Only insert or remove the microSD card or unplug connecting cables when the
instrument is switched off.
☞
The microSD card is inserted into a slot inside battery compartment A.
1. Open battery compartment A.
2. Remove the battery.
3. Remove the cover marked with SD.
4. Insert the microSD card with the logo facing upwards and lock it into position.
☞
☞
Inserting a microSD/SIM
card,
step-by-step
24
Operation
