Description of the System
Zipp02
| 7
1
Description of the System
1.1
Instrument Case
Instrument case
Before placing the instrument into
the instrument case, align the dot
mark of the in
strument upw
ard
and on the same line, and lightly
tighten the clamp knobs and loos-
ened after the instrument is
placed in the case. All the clamp
knobs must be slightly tightened
again after the instrument is in
place in the case.
