2.4 Setup
•
Keep the location clear of possible obstructions that could block or reflect the laser beam.
•
Place the Zone60 DG on stable ground. Ground vibration and extremely windy conditions
can affect the operation of the Zone60 DG.
•
When working in a very dusty environment place the Zone60 DG up-wind so the dirt is
blown away from the laser.
1. Set up the tripod.
2. Place the Zone60 DG on the tripod.
3. Tighten the screw on the underside of the tripod to secure the Zone60 DG on the tri-
pod.
☞
•
Attach the Zone60 DG securely to a tripod or laser trailer, or mount on a stable
level surface.
•
Always check the tripod or laser trailer before attaching the Zone60 DG. Make
sure all screws, bolts and nuts are tight.
•
If a tripod has chains, they should be slightly loose to allow for thermal expan-
sion during the day.
•
Secure the tripod on extremely windy days.
Location
Setting up on a tripod
18 Description of the System
