GeoMax Zone60 DG - Grade Entry and Adjustment

011187_001
When the Zone60 DG is turned on, the GeoMax Start-up screen is
shown followed by the Zone60 DG Information screen displaying the
following information:
•
Model and type
•
Serial number
•
Software revision level
•
Hours of use
GeoMax Start-up
3.4 Grade Entry
1. To start grade entry mode, press the Grade button once.
☞
To restore the last set grade(s), press and hold the Grade button for
1.5 seconds.
2. The X-axis grade value is displayed:
007590_001
3. To change the grade value, press the Up or Down Arrow buttons.
4. To enter grade on the Y-axis, press the Grade button a second time.
Only the Y-axis grade value is displayed:
007591_001
To change the grade value, press the Up or Down Arrow buttons.
To exit grade entry mode, press the Grade button until the main display is shown.
OR:
Wait for 8 seconds. The Zone60 DG automatically returns to the main display.
While in grade entry mode, you can easily change the plus/minus sign or individual digits.
1. Press the Grade button to enter the grade entry mode.
Start-up screens
Direct grade entry
Grade entry by digit
20 Operation
