5.2 Using the ZRD105B Receiver with the Zone60 DG
The Zone60 DG can be used with almost any receiver.
However, when used with the ZRD105B receiver, the following special functions are available:
•
Beam Catching - Allows you to match an existing grade. (Refer to "8.4 BeamCatching
(Grade Matching)")
•
Beam Lock - Monitors the grade position to keep it on grade. (Refer to "8.5 BeamLock
(Grade Matching and Monitoring)")
Before using the special functions, the Zone60 DG and the ZRD105B must be paired together to
be able to communicate with each other. (Refer to "5.3 Pairing the ZRD105B with the Zone60
DG")
5.3 Pairing the ZRD105B with the Zone60 DG
The Zone60 DG and the ZRD105B Receiver include radio devices that allow you to activate the
functions on the Zone60 DG remotely up to 100 m (300’) from the Zone60 DG.
Before using the RF features, the Zone60 DG and the Receiver must be paired together to be
able to communicate with each other.
1. Turn off the Zone60 DG.
2. Press and hold the Power Button on the Zone60 DG for 5 seconds to turn on the
Zone60 DG in pairing mode. The Zone60 DG beeps five times slowly.
3. Press and hold the Power Button on the Receiver until pairing is confirmed.
☞
When the pairing is successful:
Both the Zone60 DG and the Receiver beep five times and the LEDs are flashing
(green). There is no confirmation on the LCD displays during this process.
☞
When the pairing is not successful:
The Status LED on the Zone60 DG flashes (red) quickly five times.
Special functions when
using ZRD105B receiver
Pairing step-by-step
32 Receivers
