Assembly and connection
The filters are supplied in a sealed storage bag to improve their shelf life. The parts supplied should be
assembled as per the diagram shown.
Note: A soda lime CO
2
filter can also be used to zero other G Range instruments.
Soda Lime Filter
Tubing
PTFE Filter
