Reset
The instrument can be reset by pressing ‘Key 7 - Reset’ accessed via the ‘Utilities’ menu. Selecting this
option will clear all user settings and any stored data including the event log.
The following warning message will be displayed ‘This will clear user calibration and readings! Are you
sure?’ The operator is prompted to either select the ‘Accept’ button to continue or select the ‘Exit’
button to abort the reset operation.
If the operator chooses to accept a confirmation code (12345678) must be entered to confirm that a
reset is really required.
Calibration
The G200 range of instruments is fully calibrated during manufacture and when returned for service.
However, to improve accuracy between services a user/field calibration can be performed.
Note: For further information please refer to section Calibration of this manual.
View Data
The ‘View Data’ option enables the operator to view the stored readings.
From the ‘Main Read Screen’ press the ‘Menu’ key on the instrument panel.
Press ‘Key 4 - View Data’ to view the stored data readings and the following screens are
displayed:
Press ‘Key 4 - Scroll Left’ and ‘Key 6 - Scroll Right’ to move through the stored readings either
forwards or backwards. Press ‘Key 2 - Scroll Up’ and ‘Key 8 - Scroll Down’ to switch between the
first and second group of reading parameters.
Press the soft-key ‘More’ and the following menu is displayed:
Screen 16 – Soft-key ‘More’
