6
1.5.2 Rear View
Figure 1-3
No. Name Function
1 Network Connect to the network.
2 High Definition Connect to a High Definition supported display device.
3 VGA Connect to a VGA monitor.
4 Power OFF/ON Switch the power on or off.
5
DC 12V Connect to power by using the supplied power adapter.
Note: The SPDIF and L/R ports are not functional.
