GeoVision GV-IP Decoder Box User Manual

40
Specifications
Video
Video Codec H.264
High Definition VGA
480p 640 x 480
720p 1024 x 768
1080i 1280 x 768
Video Output at 60 Hz
1080p 1366 x 768
Network
Interface 10/100 Ethernet
Protocol TCP, RTSP, ONVIF, PSIA
Mechanical
IR Remote Control Yes
Power 12V DC Jack
Ethernet RJ-45
Monitor Output High Definition, VGA
Connectors
Local Storage &
Firmware Upgrade
USB slot (2.0 backward compatible, FAT32 format)
SD card slot (for Class 6 card or above, FAT32 format)
General
Operating Temperature 0°C ~ 40°C / 32 °F ~ 104 °F
Operating Humidity 20 % ~ 80 % (with no condensation)
Dimensions (W x H x D) 182.5 × 29 × 141.5 mm / 7.19 × 1.14 × 5.58 in
Net Weight 615 g / 1.36 lb
Power DC 12 V
Power Consumption 36 W (max. 3 A at 12V DC)
Regulatory CE, FCC compliant
All specifications are subject to change without notice.
