2.10 Accessory (GV-RK1352 and GV-R1352 Only)
Optional accessories can expand the capabilities and versatilities of your GV-RK1352 and
GV-R1352. Consult our sales representative for more information.
GV-MountA900
GV-MountA900 is a mounting plate that allows you to attach GV-RK1352
and GV-R1352 to a US single gang power box.

Dimensions: 100 x 68 mm / 3.9 x 2.7 in

Weight: 55 g / 0.12 lb
Connecting GV-MountA900
1. Screw GV-MountA900 to the US single gang power box through holes C.
2. Thread the cable through GV-MountA900 and then attach the reader.
 GV-R1352: Secure through holes A
 GV-RK1352: Secure through holes B
C
C
B
B
US single gang
power box
A
A
