Page 51
English
Chisel Tool
Angle
Thickness (inches)
Part number
90°
0.040
TL-056
Figure 33: Chisel tool
Punch Tools
The following part numbers are for replacement punch blades only. They
do not include the base assembly which is required to mount punches to
the tool holder.
Desired hole diameter (inches)
Part number
1/32
TL-211
1/16
TL-200
3/32
TL-201
1/8
TL-202
3/16
TL-203
1/4
TL-204
9/32
TL-210
5/16
TL-205
3/8
TL-206
1/2
TL-207
9/32
TL-210
Desired hole diameter (mm)
Part number
1
TL-250
2
TL-251
3
TL-252
4
TL-253
5
TL-254
6
TL-255
10
TL-260
Figure 34: Punch tools
