Gerber DCS 2500 - Cutter Specifications

Page 52
English
Cutter Specifications
Overall Dimensions
Lengths: 3.6, 7.3, 9.1, 10.9, 12.8,
14.6, 16.4, 18.2, 20.1, 21.9, 23.7,
25.6, 27.4, 29.2, 31, 32.9, 34.7, 36.5
m (12, 24, 30, 36, 42, 48, 54, 60, 66,
72, 78, 84, 90, 96, 102, 108, 114,
120 ft.) Widths: .9, 1.8, 2.4, 3, 3.6,
4.2 m (3, 6, 8, 10, 12, 14 ft.)
Cutting Area
Dependent on length and width of
table being used.
Table Height
0.84 m to 0.86 m
(33 in to 34 in)
Maximum Cutting/Plotting
Speed
1.1 m/sec (45 ips)
Cutting and Plotting Tools
Wheel blade, knife cutter, pen,
chisel tool, wheel,
v-notch, punch
Computer
PC based, Windows OS
Front End Systems
Compatible with Gerber; ScanVec,
Assyst, Auto-Cad, Lectra, Polygon &
most software packages
Software
CutWorks 6.0 to 10
File Formats
Gerber, DXF, AAMA, HPGL, IGES,
and others
Drive Power
Servo Motors
Drive System
Rack & pinion/belt drive hybrid
E
lectrical Requirements
Vacuum: 220V @ 15A or 440V @
7.5 Amp three phase
System Control & Drive:
110V @ 20A or 220V @ 10A single
phase
Compressed Air
Requirements
90-120 psi
Operating Environment
Max Temp 43° C (110° F)
Max Humidity 95% (non-
condensing), Stand. Vac. system to
760 m (2,500 ft.) above sea level
Figure 35: Cutter specifications
