Gesipa PH 2000 - 4 Equipment; Accessories; 5 Working Capacity; Ph 2000; Ph 2000-Bt

17
GB
Tool type PH 2000 / PH 2000-BT
Hydraulic oil, Renolin Eterna 32 (approx. ml) 30
Noise emission L
pa
(dB) 83 (measurement uncertainty K=3dB)
Vibration (m/g²)
<2.5 (measurement uncertainty K=1.5 m/s²)
4. Equipment / accessories
Tool type PH 2000 PH 2000-BT
Nosepiece in working position 16/32 16/32 BT
Nosepiece, supplied
16/24, 16/27, 16/29,
16/36, 16/40, 16/45
16/26 BT, 16/42 BT, 16/48
BT
1 pair/set jaws, tted 143 4103 143 4173
Jaw pusher, tted 145 6735 143 4167
Jaw pusher, supplied - 143 4168
Hydraulic oil 100 ml
 
1 wrench MSU
 
1 ball end screwdriver
 
1 operating instructions
 
5. Working capacity
5.1 PH 2000
For blind rivets up to Ø 5.0 mm in all materials, up to Ø 6.0 mm in aluminium, and blind
rivets from Ø 2.4 mm to 3.2 mm with small jaw assembly (item no: 143 4234) MEGA GRIP
®
blind rivets up to Ø 6.4 mm in all materials, with conversion kit required for Ø 6.4 mm (Part
No. 145 6762).
Also for plastic blind rivets Ø 4 mm, 5 mm and 6 mm.
5.2 PH 2000-BT
For BULB-TITE
®
blind rivets up to Ø 7.7 mm in all materials.
