6. Nosepiece assignment
Rivet Ø Rivet material PH 2000 Part No. PH 2000-BT Part No.
2.4 Al 10/18* 143 4055 -
3.2 CAP
®
-Al, CAP
®
-Cu 10/18* 143 4055 -
3 and 3.2
Al, Cu, steel, stainless steel,
Stinox, Al, PG Al, PG steel
10/24* 143 4061 -
4 Al, Cu, CAP
®
-Al, CAP
®
-Cu 16/24 143 4288 -
4 PG Al, steel, Al 16/27 143 4289 -
4
Stainless steel, Stinox, PG
steel
16/29 143 4290 -
4.8 and 5 Al, CAP
®
-Al, CAP
®
-Cu, PG Al 16/29 143 4290 -
4.8 and 5 Steel, Al 16/32 143 4291 -
4.8 and 5
Stainless steel, Stinox, PG
steel
16/36 143 4292 -
6 Al 16/36 143 4292 -
6 Steel 16/40 143 4293 -
6.4 Al, PG Al 16/40 143 4293 -
6.4 Al, steel 16/45 143 4300 -
4 Plastic 16/30K 143 4130 -
5 Plastic 16/35K 143 4131 -
6 Plastic 16/40K 143 4132 -
4.8 All MEGA Grip
®
16/31MG 143 4380 -
6.4 All MEGA Grip
®
16/41MG** 143 4381 -
4 All BULB-TITE
®
- 16/26BT 143 4301
5.2 All BULB-TITE
®
- 16/32BT 143 4302
6.3 All BULB-TITE
®
- 16/42BT 143 4303
7.7 All BULB-TITE
®
- 16/48BT 143 4304
* Small jaw assembly required(Part No. 143 4234)
** Conversion kit required (Part No. 145 6762)
7. Start-up
Before starting the riveting tool, read and observe the operating instructions and safety
information and keep in a safe place. Have technical personnel connect the compressed air
supply to the riveting tool.
