7.1 Selecting and changing the nosepiece
Caution:
Always t the nosepiece corresponding to the size of the blind rivet (refer to table in
Section 6).
To change the nosepiece:
• Disconnect the tool from the compressed air supply.
• Unscrew nosepiece from steel head sleeve.
• Screw in corresponding nosepiece and tighten.
7.2 To set a blind rivet
• Connect the riveting tool to the compressed air supply.
• Insert the blind rivet in the nosepiece and t as far as it will go in the hole in the material
to be joined.
• Press trigger until the mandrel breaks off.
• Release trigger.
• The spent mandrel is automatically conveyed into the spent mandrel container.
8. Sucking in and holding a blind rivet
Special function VAS
• The setting screw marked with “VAS” is reached with the supplied ball end screwdriver.
• Turning the screw 1 to max. 1.5 turns clockwise creates the suction air that holds the
blind rivet in the nosepiece.
• Only turn the setting screw so that the suction air holds the vertical blind rivet against the
nosepiece.
• Turning the screw anticlockwise shuts off the suction air.
9. Emptying the spent mandrels from the container
Caution:
The spent mandrel container must be emptied regularly; overlling will cause the
riveting tool to malfunction.
• Disconnect the tool from the compressed air supply.
• Open the spent mandrel container by turning the outer casing, empty spent mandrels into
suitable container and dispose of in corresponding recycling system.
