44
5. Remove the battery pack from its compartment.
(Battery 1 as the example)
6. Fit another battery pack into place. With the battery pack correctly
oriented, attach its connector side to the battery compartment at an
angle (
) and then press down the other side (
).
(Battery 1 as the example)
7. Slide the battery latch toward the locked position ( ).
CAUTION: Make sure the battery latch is correctly locked, not revealing the
underneath red part.
(revealing red part)
To Next Page
