6
Taking a Look at the Computer
NOTE: Depending on the specific model you purchased, the color and look
of your model may not exactly match the graphics shown in this document.
CAUTION: You need to open the protective covers to access the connectors.
When not using a connector, make sure to close the cover completely for
water- and dust-proof integrity. (Engage the locking mechanism if existing.)
Front Components
Ref
Component Description
Top cover latch
Locks the top cover.
Handle Provides a convenient way to carry the computer.
NOTE: When carrying the computer around, always
use the handle or the carrying strap (purchased
separately).
Rear Components
For covers with an arrowhead icon, push the cover toward one side to unlock
and the other side to lock. The arrowhead points to the side for unlocking.
B360
