2.7.3 Connection point for waste
WARNING!
If the waste connection is installed incorrectly,
the waste water could flow backwards into the
machine’s chamber, with the resulting risk of
contamination of goods and flooding of the
chamber.
• The connection point must have a water lock.
The connection point must be located between at least 400
mm and max 600 mm from the lower edge of the machine.
Extra thresholds or lower cabinets are not included in the
measurements.
• Connection points for sinks must created using a water lock
that is intended for this type of application.
• The connection point must have a capacity of 35 l/min and
must have a diameter of at least 40 mm.
• The hoses may be hung up using the accompanying hose
holder.
2.7.4
Check
• That the chamber does not empty on its own through the
hydrometer in the waste hose.
2 INSTALLATION
INSTALLATION MANUAL GETINGE WD15 CLARO 21 (48)
<Doc_INS><Doc_6001396702><Rev.I><Lang_en>
