2.2 Installing under bench
WARNING!
Do not place the machine close to a surface that
is sensitive to moisture such as a wall or bench
top. If needed, install protective foil to protect
surfaces that might be exposed.
Adjust the machine so that it is close to the bench top, but leave a
distance of at least 5 mm between the bench top and the top of the
machine to provide sufficient ventilation. Then put the machine
under the bench and push it as far in as possible. Adjust the front
feet so that the machine is level.
Figure 2. Adjusting screw and foot plate
1. Adjusting screw
2. Foot plate
2 INSTALLATION
12 (48) INSTALLATION MANUAL GETINGE WD15 CLARO
<Doc_INS><Doc_6001396702><Rev.I><Lang_en>
